Specifications
General
Type
Multi-Housing
Capacity
16 lb
Cylinder Volume
3.19 Cu. Ft.
Motor
0.5 hp
Maximum Speed
710 rpm
G-Force
150 g
Color
White
Manufacturer Color
White
Wash Cycles
• Soak/Prewash
• Heavy Duty/Permanent Press
• Normal Eco
• Delicate
• Heavy Duty/Permanent Press
• Normal Eco
• Delicate
Wash Basket
Stainless Steel
Water Consumption
• Water consumption per cycle - g (liter): 27.9 (106)
• IWF (water factor) - liters/liter/cycle (gal/ft³): 8.8 (1.18)
• Water pressure - p.s.i. (bar): 20-120 (1.4/8.3)
• IWF (water factor) - liters/liter/cycle (gal/ft³): 8.8 (1.18)
• Water pressure - p.s.i. (bar): 20-120 (1.4/8.3)
Features
Technologies
Automatic Balancing Suspension
Additional Information
• Curved four-vane polypropylene agitator provides 210° agitation stroke which delivers superior washability
• Low water consumption
• Manual homestyle control
• MEFJ2 (Modified Energy Factor) ft³/kWh/cycle (Liters/kWh/cycle): 1.35 (38.2)
• Water temperature: Hot, Warm, Cold
• Drain: Pump
• Agency approvals: cULus
• Low water consumption
• Manual homestyle control
• MEFJ2 (Modified Energy Factor) ft³/kWh/cycle (Liters/kWh/cycle): 1.35 (38.2)
• Water temperature: Hot, Warm, Cold
• Drain: Pump
• Agency approvals: cULus
Electrical Information
Information
• 120V/60Hz/1Ph
• 15 Amp
• 15 Amp
Dimensions
Width
25.63 inch(es) / 65.09 cm
Height
43 inch(es) / 109.22 cm
Depth
28 inch(es) / 71.12 cm
Weight
186 lb(s) / 84.37 kg
Shipping Dimensions
Width
28 inch(es) / 71.12 cm
Height
45 inch(es) / 114.3 cm
Depth
30 inch(es) / 76.2 cm
Weight
195.99 lb(s) / 88.9 kg
Warranty
Warranty
• 3-Year warranty on parts
• Limited 5-Year warranty on bearings
• Limited 5-Year warranty on bearings
